Product Overview
Buy MM75G3T65B 650V 75A IGBT Power Transistor in Pakistan. High-speed TO-247 Field Stop IGBT for inverters, UPS, welding machines and motor drives.
Description
MM75G3T65B 650V 75A IGBT Power Transistor
The MM75G3T65B 650V 75A IGBT Power Transistor is a high-efficiency switching device built using Field Stop Trench IGBT technology. Designed for demanding power electronics applications, it combines low conduction losses, fast switching performance and an integrated ultrafast freewheeling diode to improve efficiency and reliability.
With a 650V collector-emitter voltage, 75A continuous collector current (at 100°C case temperature) and TO-247 package, this device is ideal for medium- and high-power converters. Its positive temperature coefficient of VCE(sat) simplifies parallel operation, while the 175°C maximum junction temperature supports reliable operation under heavy loads.
The MM75G3T65B is widely used in solar inverters, UPS systems, servo drives, induction heating equipment, welding machines, medical equipment and industrial motor control systems.
Key Features
- 650V collector-emitter voltage
- 75A continuous collector current
- Field Stop Trench IGBT technology
- TO-247 package
- Integrated ultrafast freewheeling diode
- Low switching losses
- Low VCE(sat)
- Positive temperature coefficient
- Fast switching performance
- Maximum junction temperature 175°C
- High reliability
- RoHS compliant
Technical Specifications
| Specification | Details |
|---|---|
| Model | MM75G3T65B |
| Device Type | IGBT Power Transistor |
| Package | TO-247 |
| Collector-Emitter Voltage (VCES) | 650V |
| Continuous Collector Current | 75A (Tc = 100°C) |
| Collector Current (25°C) | 115A |
| Pulsed Collector Current | 225A |
| Gate-Emitter Voltage | ±20V |
| Maximum Junction Temperature | 175°C |
| Typical VCE(sat) | Approximately 1.45V @ 25°C |
| Technology | Trench Field Stop IGBT |
| Integrated Diode | Yes (Fast Recovery) |
Applications
Perfect for:
- Solar Inverters
- UPS Systems
- Industrial Inverters
- Servo Drives
- Motor Drives
- Welding Machines
- Induction Heating
- SMPS Power Supplies
- Medical Equipment
- Power Converters
- Industrial Automation
- High-Frequency Switching
Package Includes
- 1 × MM75G3T65B 650V 75A IGBT Power Transistor
Why Buy from Chip.pk?
- Premium quality semiconductor components
- Fast delivery across Pakistan
- Retail & wholesale pricing
- Secure packaging
- Technical support before purchase
- Trusted supplier for industrial electronics
- Reliable power semiconductor devices
Frequently Asked Questions (FAQs)
Is the MM75G3T65B suitable for solar inverter repair?
Yes. It is commonly used in solar inverters, UPS systems and industrial power converters because of its low switching losses and high current capability.
What package does this transistor use?
It comes in the TO-247 package for efficient heat dissipation.
Does it include a freewheeling diode?
Yes. The MM75G3T65B integrates a fast recovery freewheeling diode.
What gate voltage is recommended?
The device supports a ±20V gate-emitter voltage (maximum rating). Follow the datasheet recommendations for your specific gate driver design.
Which gate driver IC works well with this IGBT?
Common isolated gate drivers include the TLP250H, HCPL-3120, ACPL-332J and similar IGBT gate driver ICs, depending on your application requirements.
