1-8S Lithium Battery Capacity Indicator Module 3.7V-33.6V Power Level Display

The 1-8S Lithium Battery Capacity Indicator Module is a compact battery monitoring module designed to display the remaining charge level of 1S to 8S lithium battery packs. Supporting an input voltage range of 3.7V to 33.6V, it provides a clear LED power level indication, making it ideal for Li-ion, LiPo, electric bicycles, scooters, solar systems, robotics, and DIY battery-powered projects.

Description

1-8S Lithium Battery Capacity Indicator Module 3.7V-33.6V Power Level Display

The 1-8S Lithium Battery Capacity Indicator Module is a practical battery monitoring solution that provides a quick visual indication of the remaining charge level in lithium battery packs. Designed to support 1-cell to 8-cell (1S-8S) lithium batteries, it operates across a voltage range of 3.7V to 33.6V, making it suitable for numerous portable and industrial applications.

This compact module uses high-brightness LED indicators to display the approximate battery capacity, helping users monitor battery status without additional measuring equipment. It is ideal for electric bicycles, electric scooters, robotics, DIY battery packs, UPS systems, solar energy storage, portable power stations, RC projects, and embedded electronics.

The module is easy to install and features low power consumption, making it suitable for continuous battery monitoring. Its compact PCB design allows seamless integration into custom enclosures, battery packs, and electronic devices where reliable battery level indication is required.

Key Features

• Supports 1S to 8S lithium battery packs
• Operating voltage range: 3.7V–33.6V
• High-brightness LED battery level display
• Real-time battery capacity indication
• Compact PCB design
• Low power consumption
• Easy wiring and installation
• Stable and reliable performance
• Suitable for Li-ion battery packs
• Compatible with LiPo battery packs
• Battery percentage indication
• Fast battery status monitoring
• Lightweight construction
• Durable electronic design
• Ideal for DIY battery projects
• Perfect for electric vehicles and robotics

Technical Specifications

Applications

The 1-8S Lithium Battery Capacity Indicator Module is ideal for monitoring the charge level of lithium battery packs in a wide range of applications, including:

• Electric Bicycles (E-Bikes)
• Electric Scooters
• Electric Motorcycles
• Electric Vehicles (EVs)
• Lithium Battery Packs
• Li-ion Battery Systems
• LiPo Battery Packs
• Solar Energy Storage Systems
• Portable Power Stations
• UPS Battery Systems
• DIY Battery Projects
• Robotics Projects
• RC Cars, Boats & Drones
• Battery Backup Systems
• Industrial Equipment
• Medical Devices
• Portable Electronic Devices
• Embedded Electronics
• Power Banks
• Battery Testing Projects

Compatibility

The module supports most rechargeable lithium battery packs operating between 3.7V and 33.6V.

Compatible Battery Packs

• 1S Lithium Battery (3.7V)
• 2S Lithium Battery (7.4V)
• 3S Lithium Battery (11.1V)
• 4S Lithium Battery (14.8V)
• 5S Lithium Battery (18.5V)
• 6S Lithium Battery (22.2V)
• 7S Lithium Battery (25.9V)
• 8S Lithium Battery (29.6V–33.6V)

Compatible Battery Types

• Lithium-ion (Li-ion)
• Lithium Polymer (LiPo)
• 18650 Battery Packs
• 21700 Battery Packs
• Rechargeable Lithium Battery Packs

Note: This module is intended for lithium-based battery packs only. It is not suitable for lead-acid, NiMH, or NiCd batteries unless specifically calibrated for those chemistries.

Package Includes

• 1 × 1-8S Lithium Battery Capacity Indicator Module

Important Notes

• Supports 1S to 8S lithium battery packs.
• Operating voltage range: 3.7V–33.6V DC.
• Check wiring polarity before connecting the module.
• Designed for battery capacity indication only; it does not charge or protect batteries.
• Install according to the product's wiring diagram.
• Avoid exceeding the supported voltage range.
• Suitable for indoor electronic applications.
• Keep away from moisture and conductive debris.
