XL6009 DC-DC Adjustable Boost Converter Step-Up Power Supply Module
XL6009 DC-DC Adjustable Boost Converter Step-Up Power Supply Module
Product Overview
Increase DC voltage efficiently with the XL6009 DC-DC Boost Converter Module. Featuring adjustable output voltage, high conversion efficiency, and compact design, it's ideal for Arduino, ESP32, battery-powered devices, solar systems, robotics, and DIY electronics.
Description
The XL6009 DC-DC Adjustable Boost Converter Module is a high-efficiency step-up voltage regulator designed to convert a lower DC input voltage into a higher adjustable output voltage. Powered by the reliable XL6009 switching regulator IC, this module delivers stable output with excellent efficiency while minimizing heat generation.
Equipped with a large inductor, precision adjustment potentiometer, and dual aluminum heatsinks, the module is suitable for powering electronic devices that require a higher voltage than the available power source. It is widely used in battery-powered equipment, solar energy systems, LED drivers, automotive electronics, industrial control systems, and embedded applications.
Compatible with Arduino, ESP32, ESP8266, Raspberry Pi, STM32, and other development platforms, the XL6009 module is an excellent choice for makers, students, engineers, and professionals seeking a reliable DC voltage booster.
Applications
- Battery Voltage Boosting
- Arduino Projects
- ESP32 Projects
- Raspberry Pi Power Systems
- Solar Power Systems
- LED Drivers
- Robotics
- Portable Power Supplies
- Industrial Automation
- Automotive Electronics
- Embedded Systems
- DIY Electronics
- Laboratory Projects
- Renewable Energy Applications
Key Features
- XL6009 Boost Converter IC
- Adjustable Output Voltage
- High Conversion Efficiency
- Step-Up Voltage Regulation
- Dual Aluminum Heatsinks
- Multi-Turn Voltage Adjustment
- Compact PCB Design
- Screw Terminal Connections
- Stable Output Performance
- Suitable for High-Efficiency Power Applications
Technical Specifications
| Specification | Value |
|---|---|
| Product Type | DC-DC Boost Converter Module |
| Controller IC | XL6009 (Please confirm before publishing.) |
| Converter Type | Step-Up (Boost) |
| Input Voltage | 3V–32V DC |
| Output Voltage | 5V–35V DC Adjustable |
| Maximum Output Current | Up to 4A (with adequate cooling) |
| Conversion Efficiency | Up to 94% |
| Output Adjustment | Multi-Turn Potentiometer |
| Cooling | Dual Aluminum Heatsinks |
| Switching Frequency | Approximately 400kHz |
Package Includes
- 1 × XL6009 DC-DC Adjustable Boost Converter Module
Datasheet Summary
| Parameter | Details |
|---|---|
| Controller IC | XL6009 |
| Converter Type | Step-Up (Boost) |
| Input Voltage | 3V–32V DC |
| Output Voltage | 5V–35V Adjustable |
| Maximum Output Current | Up to 4A |
| Efficiency | Up to 94% |
| Switching Frequency | Approximately 400kHz |
| Cooling | Dual Aluminum Heatsinks |
How It Works
The XL6009 module uses high-frequency switching technology to boost a lower DC input voltage to a higher adjustable output voltage. The onboard potentiometer allows precise output voltage adjustment, while the large inductor and heatsinks ensure stable, efficient operation with reduced heat generation.
