Product Overview
XH-M602 Digital Battery Low Voltage Disconnect Protection Module for 12V–36V battery systems, solar power, UPS, lithium batteries and automatic charging control.
Description
XH-M602 Digital Battery Low Voltage Disconnect Protection Module 12V–36V
The XH-M602 Digital Battery Low Voltage Disconnect Protection Module is an intelligent battery voltage monitoring and charging control module designed to protect batteries from over-discharge and overcharging. It continuously monitors battery voltage and automatically controls charging equipment through its onboard relay according to user-defined voltage thresholds. Modules in the XH-M602 family are commonly used with lead-acid and lithium battery systems and offer digital voltage monitoring with 0.1 V display accuracy.
This module is widely used in solar energy systems, UPS backups, battery chargers, electric vehicles, DIY battery packs and industrial power systems. By disconnecting or reconnecting charging equipment automatically, it helps extend battery life and reduce unnecessary charging cycles. Typical XH-M602 boards are powered from AC mains and control the charger through an onboard relay.
Key Features
- Digital battery voltage display
- Automatic battery charging control
- Low voltage disconnect protection
- Adjustable start and stop voltage
- High-precision voltage monitoring
- Built-in relay output
- Easy parameter configuration
- Bright LED digital display
- Suitable for lithium and lead-acid batteries
- Helps extend battery life
- Reliable battery protection
- Easy screw terminal connections
Technical Specifications
| Specification | Details |
|---|---|
| Model | XH-M602 |
| Module Type | Battery Charging Control Module |
| Display | Digital LED |
| Display Accuracy | 0.1V |
| Control Accuracy | 0.1V |
| Relay Output | Yes |
| AC Input | 110–220V AC (varies by version) |
| Battery Monitoring | Adjustable Voltage Threshold |
| Compatible Batteries | Lithium & Lead-Acid |
| Applications | Battery Charging, Solar, UPS, EV, DIY Projects |
Applications
Perfect for:
- Solar Battery Systems
- UPS Battery Backup
- Lead Acid Batteries
- Lithium Battery Packs
- Battery Chargers
- Electric Vehicles
- Portable Power Systems
- DIY Battery Projects
- Industrial Power Systems
- Energy Storage Systems
- Battery Maintenance
- Off-Grid Power Systems
Package Includes
- 1 × XH-M602 Digital Battery Low Voltage Disconnect Protection Module
Why Buy from Chip.pk?
- Genuine electronic modules
- Directly imported from trusted manufacturers
- Fast delivery across Pakistan
- Retail and wholesale quantities available
- Technical support before purchase
- Secure packaging
- Trusted supplier for electronics, solar and battery projects
Frequently Asked Questions (FAQs)
What is the XH-M602 used for?
The XH-M602 automatically monitors battery voltage and controls battery charging by switching a relay at user-defined voltage levels, helping protect batteries from overcharging or excessive discharge.
Can this module be used with lithium batteries?
Yes. It is commonly used with lithium battery packs as well as lead-acid batteries, provided the voltage range matches your battery system.
Is the charging voltage adjustable?
Yes. Users can set both the charging start voltage and charging stop voltage using the onboard buttons and digital display.
Can I use it in a solar system?
Yes. It is suitable for many solar battery charging applications where automatic voltage-based charging control is required.
Does this module include a battery charger?
No. The XH-M602 is a battery charging controller. It controls an external charger through its relay output; it is not a charger itself.
