TB6600 Stepper Motor Driver Module for NEMA 17, NEMA 23 & CNC Machines
TB6600 Stepper Motor Driver Module for NEMA 17, NEMA 23 & CNC Machines
Product Overview
Drive high-torque bipolar stepper motors with the TB6600 Stepper Motor Driver Module. Featuring adjustable current, selectable microstepping, and reliable protection features, it's ideal for CNC machines, laser engravers, 3D printers, robotics, and industrial automation.
Description
The TB6600 Stepper Motor Driver Module is a professional-grade motor controller designed to drive bipolar stepper motors with smooth, accurate, and reliable motion control. Built for demanding CNC and automation applications, it supports adjustable output current and multiple microstepping modes for improved precision and reduced vibration.
Compatible with Arduino, ESP32, Raspberry Pi (via external motion controllers), STM32, PLCs, Mach3 controllers, GRBL systems, and other motion control platforms, the TB6600 is widely used in CNC routers, laser engravers, XY tables, robotic systems, camera sliders, pick-and-place machines, and industrial automation equipment.
Its robust enclosure and integrated heatsink provide efficient cooling for continuous operation, while DIP switches allow quick configuration of current limits and microstepping settings.
Whether you're building a CNC machine, upgrading a 3D printer, or developing a precision motion system, the TB6600 offers dependable performance for professional and DIY applications.
Applications
- CNC Routers
- CNC Milling Machines
- Laser Engravers
- NEMA 17 Stepper Motors
- NEMA 23 Stepper Motors
- Robotics
- XY Motion Systems
- Camera Sliders
- Pick and Place Machines
- Industrial Automation
- Arduino CNC Projects
- ESP32 Motion Control
- DIY Electronics
- STEM Education
Key Features
- TB6600 Stepper Motor Driver
- Supports Bipolar Stepper Motors
- Adjustable Output Current
- Selectable Microstepping Modes
- High-Speed Pulse Input
- Built-In Overcurrent Protection
- Overheat Protection
- Short Circuit Protection
- Integrated Aluminum Heatsink
- Easy DIP Switch Configuration
Technical Specifications
| Specification | Value |
|---|---|
| Product Type | Stepper Motor Driver Module |
| Driver IC | TB6600 |
| Motor Type | Bipolar Stepper Motor |
| Microstepping | Configurable via DIP Switches |
| Current Adjustment | Adjustable |
| Signal Interface | PUL, DIR, ENA |
| Input Terminal | Screw Terminal |
| Cooling | Integrated Aluminum Heatsink |
Package Includes
1 Ã TB6600 Stepper Motor Driver Module
Datasheet Summary
- TB6600 Stepper Driver
- DIP Switch Configuration
- Screw Terminal Connections
- Aluminum Heatsink
- Enclosed Driver Housing
How It Works
The TB6600 receives PULSE (STEP) and DIRECTION (DIR) signals from a motion controller or microcontroller. Each pulse advances the stepper motor by one step or microstep, while the direction signal determines clockwise or counterclockwise rotation. Current and microstepping settings are configured using the onboard DIP switches to match the motor's specifications for smooth, precise motion.
