AC-DC Isolated Switching Power Supply Module for Embedded & DIY Electronics
AC-DC Isolated Switching Power Supply Module for Embedded & DIY Electronics
Product Overview
Convert AC mains power into stable DC output with this compact AC-DC Isolated Switching Power Supply Module. Ideal for smart home devices, industrial automation, Arduino, ESP32, IoT systems, and embedded electronics.
Description
The AC-DC Isolated Switching Power Supply Module is a compact open-frame power converter designed to efficiently convert AC mains voltage into a regulated DC output for electronic circuits and embedded systems. Featuring an isolated switching design, it provides reliable and stable power while maintaining electrical isolation between the AC input and DC output.
Its compact PCB layout makes it suitable for integration into space-constrained products such as smart home devices, industrial controllers, automation systems, IoT equipment, LED controllers, security systems, and embedded electronics.
This module is commonly used to power Arduino, ESP32, ESP8266, Raspberry Pi (through suitable regulation), relay modules, sensors, microcontroller-based projects, and custom electronic products. High-efficiency switching technology minimizes heat generation while delivering dependable long-term performance.
Whether you're designing commercial electronics or building DIY automation projects, this AC-DC converter offers an efficient and reliable power solution.
Applications
- AC to DC Power Conversion
- Arduino Projects
- ESP32 Projects
- ESP8266 Projects
- Raspberry Pi Power Systems
- Smart Home Devices
- IoT Systems
- Industrial Automation
- LED Controllers
- Security Systems
- Embedded Electronics
- DIY Electronics
- Control Panels
- Electronic Prototypes
Key Features
- AC to DC Switching Power Supply
- Isolated Power Conversion
- Compact Open-Frame Design
- High Conversion Efficiency
- Stable DC Output
- Low Ripple Output
- Reliable Long-Term Operation
- Easy PCB Integration
- Suitable for Embedded Applications
- Ideal for Industrial & DIY Projects
Technical Specifications
| Specification | Value |
|---|---|
| Product Type | AC-DC Switching Power Supply Module |
| Converter Type | Isolated Switching Power Supply |
| Input | AC Mains |
| Output | Regulated DC Output |
| Isolation | Yes |
| Mounting | PCB Mount |
| PCB Type | Open Frame |
Package Includes
1 Ã AC-DC Isolated Switching Power Supply Module
Datasheet Summary
- AC-DC Power Supply Module
- Isolated Switching Design
- Compact PCB Layout
- Open-Frame Construction
How It Works
The module accepts AC mains input and converts it into a stable DC output using high-frequency switching technology and an isolated transformer. Internal rectification, filtering, and regulation circuits ensure efficient voltage conversion while maintaining electrical isolation between the input and output, making it suitable for safely powering embedded electronics and automation systems.
